| Model BSMJ | Rated line voltage (KV) | Rated phase voltage (KV) | Three-phase capacity (Kvar) | Rated Capacity (μF) | Rated Current (A) | Dimension (mm) | Connection | Bottom Bolt |
| 0.25-2.5-3 | 250 | 2.5 | 127.4 | 5.8 | 50 | 76×180 | △ | M12×16 |
| 0.25-3-3 | 250 | 3 | 152.8 | 6.9 | 50 | 76×180 | △ | M12×16 |
| 0.25-4-3 | 250 | 4 | 203.8 | 9.2 | 50 | 76×240 | △ | M12×16 |
| 0.25-5-3 | 250 | 5 | 254.7 | 11.7 | 50 | 76×240 | △ | M12×16 |
| 0.25-6-3 | 250 | 6 | 305.7 | 13.9 | 50 | 76×240 | △ | M12×16 |
| 0.25-7.5-3 | 250 | 7.5 | 382.1 | 17.3 | 50 | 76×240 | △ | M12×16 |
| 0.25-8-3 | 250 | 8 | 407.6 | 18.5 | 50 | 96×240 | △ | M16×25 |
| 0.25-10-3 | 250 | 10 | 509.4 | 23.1 | 50 | 96×240 | △ | M16×25 |
| 0.25-12.5-3 | 250 | 12.5 | 636.8 | 28.9 | 50 | 106×240 | △ | M16×25 |
| 0.28-2.5-3 | 280 | 2.5 | 101.5 | 5.2 | 50 | 76×180 | △ | M12×16 |
··············································
